| 扫路机参数 Road sweeper parameters | |||||
| 滚刷直径 Brush diameter（mm） | 660 | ||||
| 边刷 Side brushes | 左右边刷 Brush left and right | ||||
| 滚刷材质 Roller brush material | 加强钢丝尼龙过混合 Reinforced steel wire nylon over mixing | ||||
| 边刷蕞大直径 Maximum diameter of side brushes（mm） | 600 | ||||
| 边刷材质 Edge brush material | 钢片+粗细尼龙混编 Steel sheet + thick and thin nylon mixing | ||||
| 装置尺寸 Dimensions of the device(mm) | 2100*2400*1000 | ||||
| 滚刷蕞高转速 The maximum speed of the roller brush（r/min） | 260 | ||||
| 蕞大清扫宽度 Maximum sweeping width（mm） | 2200-2400 | ||||
| 垃圾箱清扫宽度 Dustbin sweeping width（mm） | 1600-1800 | ||||
| 工作装置操作方式 The operation mode of the working device | 机械弹手柄操作 Mechanical elastic handle operation | ||||
| 散热系统 Cooling system | 独立双油散 Independent double oil dispersion | ||||
| 液压系统H ydraulics | 双泵双阀 Twin pumps and double valves | ||||
| 双水箱总容积 Total volume of double water tanks（L) | 1500 | ||||
| 垃圾箱容积 Dustbin volume（m3） | 1 | ||||
| 洒水系统 Sprinkler system | 电动分控式Electric sub-control | ||||
| 清扫能力 Sweeping capacity（m3/h） | 25000 | ||||
| 升降方式Lifting mode | 动臂升降 Boom lifting | ||||
